58 HAC Standard fixing - 02/2018dormakaba c-lever pro
• Align the cover (1).
• Move the cover in the sequence shown (2–3) and insert it into the groove (4).
-> The cover protrudes on the side opposite the groove.
• Press the protruding cover against the frame (5) and hold down.
1.
2.
3.
4.
5.
• Tighten the union nut using the multitool.
• Let go of the cover.
• Carry out a function check, see Operation [}6].
8.3 Replacing the TouchGo media battery
See dormakaba c-lever TouchGo operating instructions
