Instructions for use Isolette 8000 plus SW 5.n 151
Service
13.5.1.1 Air inlet filter maintenance
Check the air inlet filter during each preventive maintenance cycle. Replace the
filter if it is damaged, visibly dirty, or older than 3 months.
1 To remove the air inlet filter cover, loosen the 2 thumbscrews (A).
2 Remove the old air inlet filter and install a new one (B). Orient the filter so that
the side with the text “THIS SIDE OUT” faces the inside of the air inlet filter
cover.
3 Install the air inlet filter cover, and tighten the 2 thumbscrews.
13.5.1.2 Fuse replacement
1 Disconnect the Isolette 8000 plus from electrical power.
2 Using a small screwdriver or similar tool, pry open the fuse holder cover (C) on
the on/off switch module on the height adjustment trolley.
3 Remove the fuse holder and replace the fuse (or fuses) (T10AL250V).
4 Reinstall the fuse holder and reinstall the cover onto the on/off switch module.
