Instructions for use Isolette 8000 plus SW 5.n 67
Getting started
3 To release the hood, pull on and hold the knob (C) on the right rear hinge
while closing the hood.
4 If equipped with a weighing scale, reconnect the weighing scale cable as
follows
– Rotate the locking knobs and open the front or rear access panel.
– Reconnect the weighing scale cable to the sensor module.
– Close the access panel, and rotate both latches until they are fully
engaged.
3 If equipped with the optional iris ports on the side access panels, rotate the outer
ring (A) of the iris ports.
The iris port opens and closes as rotation is continued through 360 °.
4 Check the hand port latches and gaskets.
1 Press the latch (B) on each hand port.
The door swings open.
028085
