Instructions for use Isolette 8000 plus SW 5.n 73
Getting started
4 Repeat steps 2 and 3 for the foot pedal at the rear of the device.
7.2.4 Castor wheel lock functional check
1 Press the castor wheel locks (B) and ensure that they keep the device from
moving.
2 Release the locks and ensure that the device can move freely.
7.2.5 Rail system functional check
Proper latching of rail components to the rail is both visually and physically evident
to the user.
7.2.5.1 Fairfield-compatible rail (A) (cross section shown):
Verify that all cam adapter latches are properly secured to the Fairfield-compatible
rail when in the locked position.
The mounting adapters lock when the toggle handle is switched to the left
position (8 o’clock) (B). They unlock when the toggle handle is switched to the
right position (4 o’clock) (C).
066
A
B
082069
A
B
C
