Available settings are explained as follows:
Item Description
Show / Hide Advanced
Mode
Click to show or hide the advanced settings for virtual WAN.
Name Enter a name as the profile name.
Enabled Switch the toggle to enable or disable the function.
General
Physical Interface Displays the WAN type (e.g., DSL) of the physical interface.
ADSL Setting VPI - Enter the value provided by ISP.
VCI - Enter the value provided by ISP.
Customer VLAN - Click to enable the function of VLAN with tag. If
enabled,
Tag - Enter the value as the VLAN ID number. The range is from 0
to 4094.
Priority - Enter the packet priority number for such VLAN. The
range is from 0 to 7.
VDSL2 Setting Tag - Enter the value as the VLAN ID number. The range is from 0 to
4094.
Priority - Enter the packet priority number for such VLAN. The range
is from 0 to 7.
Port-Based Bridge
Port Bridge Switch the toggle to enable or disable the function.
Binding Interface - Click +Add to add an interface for binding.
IPv4
