Vigor2926 Series User’s Guide
112
connection.
When you finish the configuration, please click OK to save and exit this page.
I
I
I
I
-
-
2
2
-
-
1
1
-
-
2
2
D
D
e
e
t
t
a
a
i
i
l
l
s
s
P
P
a
a
g
g
e
e
f
f
o
o
r
r
L
L
A
A
N
N
2
2
~
~
L
L
A
A
N
N
5
5
a
a
n
n
d
d
D
D
M
M
Z
Z
Available settings are explained as follows:
Item Description
Network Configuration Enable/Disable - Click Enable to enable such configuration;
click Disable to disable such configuration.
For NAT Usage - Click this radio button to invoke NAT
function.
For Routing Usage - Click this radio button to invoke this
function.
IP Address - Type in private IP address for connecting to a
local private network (Default: 192.168.1.1).
Subnet Mask - Type in an address code that determines the
size of the network. (Default: 255.255.255.0/ 24)
DHCP Server
Configuration
DHCP stands for Dynamic Host Configuration Protocol. The
router by factory default acts a DHCP server for your network
so it automatically dispatch related IP settings to any local
user configured as a DHCP client. It is highly recommended
that you leave the router enabled as a DHCP server if you do
not have a DHCP server for your network.
Enable Server - Let the router assign IP address to every host
in the LAN.
Disable Server – Let you manually assign IP address to every
host in the LAN.
Enable Relay Agent - If you want to use another DHCP server
in the network other than the Vigor Router’s, you can let
Relay Agent help you to redirect the DHCP request to the
specified location.
DHCP Server IP Address – It is available when Enable Relay
Agent is checked. Set the IP address of the DHCP server you
are going to use so the Relay Agent can help to forward the
