Available settings are explained as follows:
Item Description
Mode Analyze a single packet – Choose such mode to make Vigor
router analyze how a single packet will be sent by a route
policy.
Analyze multiple packets… - Choose such mode to make
Vigor router analyze how multiple packets in a specified
file will be sent by a route policy.
Packet Information Specify the nature of the packets to be analyzed by Vigor
router.
ICMP/UDP/TCP/ANY- Specify a protocol for diagnosis.
Src IP – Type an IP address as the source IP.
Dst IP – Type an IP address as the destination IP.
Dst Port – Use the drop down list to specify the destination
port.
Analyze – Click it to perform the job of analyzing. The
analyzed result will be shown on the page. If required, click
export analysis to export the result as a file.
Input File Select – Click the download link to get a blank example
file. Then, click such button to select that blank “.csv” file
for saving the result of analysis.
Analyze – Click it to perform the job of analyzing. The
analyzed result will be shown on the page. If required, click
export analysis to export the result as a file.
