Vigor2926 Series User’s Guide
461
Specific Limitation
IP – All the IPs within the range defined will be restricted by
bandwidth limit defined by TX Limit and RX Limit below.
 Start IP - Define the start IP address for limit
bandwidth.
 End IP - Define the end IP address for limit bandwidth.
Object – All the IPs specified by the selected IP object or IP
group will be restricted by bandwith limit defined by TX
Limit and RX Limit below.
 IP Group – Specify an IP group by using the drop down
list.
 IP Object - Specify an IP object by using the drop down
list.
Each / Shared - Select Each to make each IP within the range
of Start IP and End IP having the same speed defined in TX
limit and RX limit fields; select Shared to make all the IPs
within the range of Start IP and End IP share the speed
defined in TX limit and RX limit fields.
TX limit - Define the limitation for the speed of the
upstream. If you do not set the limit in this field, the system
will use the default speed for the specific limitation you set
for each index.
RX limit - Define the limitation for the speed of the
downstream. If you do not set the limit in this field, the
system will use the default speed for the specific limitation
you set for each index.
Add - Add the specific speed limitation onto the list above.
Edit - Allow you to edit the settings for the selected
limitation.
Delete - Remove the selected settings existing on the
limitation list.
Allow auto adjustment to
assign available …
Check this box to make the best utilization of available
bandwidth.
Smart Bandwidth Limit Check this box to have the bandwidth limit determined by
the system automatically.
TX limit - Define the limitation for the speed of the
upstream. If you do not set the limit in this field, the system
will use the default speed for the specific limitation you set
for each index.
RX limit - Define the limitation for the speed of the
downstream. If you do not set the limit in this field, the
system will use the default speed for the specific limitation
you set for each index.
Time Schedule Index (1-15) in Schedule Setup - You can type in four sets of
time schedule for your request. All the schedules can be set
previously in Application >> Schedule web page and you can
use the number that you have set in that web page.
