Vigor2926 Series User’s Guide
517
Enter Mobile
Number Description
Enter message to be displayed in the mobile number textbox to
prompt the user to enter the mobile number.
Send Button
Description
Enter the label text of the send button.
Send Button Color Select the color of the send button from the predefined color list,
or select Customize Color and enter the RGB value. Click Preview
to preview the selected color.
Send Succeeded
Message
Enter text to be displayed to notify the user after the PIN has been
sent.
Save and Next Click to save the configuration on this page and proceed to the
next page.
Cancel Click to abort the configuration process and return to the profile
summary page.
4
4
.
.
W
W
h
h
i
i
t
t
e
e
l
l
i
i
s
s
t
t
S
S
e
e
t
t
t
t
i
i
n
n
g
g
In this step you can configure the whitelist settings. Users are allowed to send and receive
traffic that satisfies whitelist settings.
Available settings are explained as follows:
Item Description
NAT Rules To prevent web portal settings from conflicting with NAT rules
resulting in unexpected behavior, select the NAT rules that are
allowed to bypass the web portal. Hosts listed in selected NAT
rules can always access the Internet without being intercepted by
the web portal.
Dest Domain Enter up to 30 destination domains that are allowed to be
accessed.
Dest IP Enter up to 30 destination IP addresses that are allowed to be
accessed.
Dest Port Enter up to 30 destination protocols and ports that are allowed
through the router.
Source IP Enter up to 30 source IP addresses that are allowed through the
router.
