Vigor2926 Series User’s Guide
603
To set a new profile, please do the steps listed below:
1. Click the number (e.g., #1) under Index column for configuration in details.
2. The configuration page will be shown as follows:
Available settings are explained as follows:
Item Description
Name Type a name for this profile. Maximum 15 characters are
allowed.
Address Type Determine the address type for the IPv6 address.
Select Single Address if this object contains one IPv6 address
only.
Select Range Address if this object contains several IPv6s
within a range.
Select Subnet Address if this object contains one subnet for
IPv6 address.
Select Any Address if this object contains any IPv6 address.
Select Mac Address if this object contains Mac address.
Mac Address Type the MAC address of the network card which will be
controlled.
Start IP Address Type the start IP address for Single Address type. Or, click
Select to specify an IP address.
End IP Address Type the end IP address if the Range Address type is
selected. Or, click Select to specify an IP address.
Prefix Length Type the number (e.g., 64) for the prefix length of IPv6
address.
Invert Selection If it is checked, all the IPv6 addresses except the ones listed
above will be applied later while it is chosen.
3. After finishing all the settings, please click OK to save the configuration.
