Vigor2926 Series User’s Guide
855
0 – disable the substitution.
channel – 0 (FXS 1) -1 (FXS 2)
value – 0 – 9
voip dsp setRingThres
port Set the threshold for ring signal.
Port setting is “0” only.
value Available settings 0-250. Unit is ms.
The time is an approximate value.
voip dsp setCidDetGain
tx|rx gain Set the gain value of caller ID detected.
Tx gain – Available settings -24 ~ 12. Default is 0.
Rx gain – Available settings -24 ~ 12. Default is -6.
E
E
x
x
a
a
m
m
p
p
l
l
e
e
> voip dsp countrytone ?
VoIP has been disable. Please enable VoIP first.
> voip sip misc –D 0
System reboot now!
> voip dsp countrytone ?
> Vigor> voip dsp countrytone?
usage:
voip dsp countrytone [channel][value]
[channel]: 1-2
[value]: ( [2] UK, [3] USA, [4] Denmark, [5] Italy, [6] Germany, [7] Netherland
s, [8] Portugal, [9] Sweden, [10] Australia, [11] Slovenia, [12] Czech, [13]
Slovakia, [14] Hungary, [15] Switzerland , [16] France , [17] Malta)
============ Channel=1 ===================
current country tone: user defined
----------- ( Dial tone ) --------------------
Feq1=425, Feq2=0, OneOn=0, Off=0, TwoOn=0, TwoOff=0
----------- ( Ringing tone ) -----------------
Feq1=425, Feq2=0, OneOn=1500, OneOff=3000, TwoOn=0, TwoOff=0
----------- ( Busy tone ) --------------------
Feq1=425, Feq2=0, OneOn=200, OneOff=200, TwoOn=0, TwoOff=0
============ Channel=2 ===================
current country tone: user defined
> voip dsp dialtonepwr 1 20
Current power level of dialtone:20 (-13 db), channel=1
> voip dsp setCidDetGain tx 1
Current CID Detect Tx Gain [1], Rx Gain [-6]
> voip dsp setCidDetGain rx 3
Current CID Detect Tx Gain [1], Rx Gain [3]
T
T
e
e
l
l
n
n
e
e
t
t
C
C
o
o
m
m
m
m
a
a
n
n
d
d
:
:
v
v
o
o
i
i
p
p
r
r
t
t
p
p
S
S
y
y
n
n
t
t
a
a
x
x
voip rtp codec [sip acc index][type|size|vad|one][value]
voip rtp dtmf [index] [mode|payloadtype][value]
voip rtp port [start|end] [value]
