Vigor2926 Series User’s Guide
901
enable It means to enable the WMM for each SSID.
0: disable
1: enable
Apsd [value] It means to enable / disable the ASPD(automatic power-save
delivery) function.
0: disable
1: enable
show It displays current status of WMM.
QueIdx It means the number of the queue which the WMM settings will be
applied to. There are four queues, best effort, background, voice,
and video.
Aifsn It controls how long the client waits for each data transmission.
Cwmin/ Cwmax CWMin means contention Window-Min and CWMax means
contention Window-Max. Specify the value ranging from 1 to 15.
Txop It means transmission opportunity. Specify the value ranging from 0
to 65535.
ACM It can restrict stations from using specific category class if it is
enabled.
0: disable
1: enable
E
E
x
x
a
a
m
m
p
p
l
l
e
e
> wl wmm ap 0 3 4 6 0 0
QueIdx=0: APAifsn=3,APCwmin=4,APCwmax=6, APTxop=0,APACM=0
> wl wmm enable 1 0 1 0
WMM_SSID0 =1, WMM_SSID1 =0,WMM_SSID2 =1,WMM_SSID3 =0
> wl wmm show
Enable WMM: SSID0 =1, SSID1 =0,SSID2 =1,SSID3 =0
APSD=0
QueIdx=0: APAifsn=3,APCwmin=4,APCwmax=6, APTxop=0,APACM=0
QueIdx=1: APAifsn=7,APCwmin=4,APCwmax=10, APTxop=0,APACM=0
QueIdx=2: APAifsn=1,APCwmin=3,APCwmax=4, APTxop=94,APACM=0
QueIdx=3: APAifsn=1,APCwmin=2,APCwmax=3, APTxop=47,APACM=0
QueIdx=0: BSSAifsn=3,BSSCwmin=4,BSSCwmax=10, BSSTxop=0,BSSACM=0
QueIdx=1: BSSAifsn=7,BSSCwmin=4,BSSCwmax=10, BSSTxop=0,BSSACM=0
QueIdx=2: BSSAifsn=2,BSSCwmin=3,BSSCwmax=4, BSSTxop=94,BSSACM=0
QueIdx=3: BSSAifsn=2,BSSCwmin=2,BSSCwmax=3, BSSTxop=47,BSSACM=0
AckPolicy[0]=0: AckPolicy[1]=0,AckPolicy[2]=0,AckPolicy[3]=0
