Vigor2926 Series User’s Guide
914
wl_dual wds show
wl_dual wds mac add [index addr]
wl_dual wds mac clear/disable/enable [index/all]
wl_dual wds flush
S
S
y
y
n
n
t
t
a
a
x
x
D
D
e
e
s
s
c
c
r
r
i
i
p
p
t
t
i
i
o
o
n
n
Parameter Description
mode [value] It means to specify connection mode for WDS.
[value]: Available settings are :
d: Disable
b: Bridge
r: Repeapter
security [value] It means to configure security mode with encrypted keys for WDS.
mode: Available settings are:
disable: No security.
wep: WEP
wpapsk [key]: WPA/PSK
wpa2psk [key]: WPA2/PSK
key: Moreover, you have to add keys for wpapsk, wpa2psk, and wep,
and specify index number of schedule profiles to be followed by the
wireless connection.
WEP keys must be in 5/13 ASCII text string or 10/26 Hexadecimal
digit format; WPA keys must be in 8~63 ASCII text string or 64
Hexadecimal digit format.
e.g.,
wl_dual wds security disable
wl_dual wds security wep 12345
wl_dual wds security wpa2psk 12345678
ap [value] It means to enable or disable the AP function.
Value: 1 – enable the function.
0 – disable the function.
hello [value] It means to send hello message to remote end (peer).
Value: 1 – enable the function.
0 – disable the function.
status It means to display WDS link status for 5GHz connection.
show It means to display current WDS settings.
mac add [index addr] add [index addr] – Add the peer MAC entry in Repeater/Bridge WDS
MAC table.
mac clear/disable/enable
[index/all]
clear/disable/enable [index/all]- Clear, disable, enable the
specifed or all MAC entries in Repeater/Bridge WDS MAC table. e.g,
wl_dual wds mac enable 1
flush It means to reset all WDS setting.
E
E
x
x
a
a
m
m
p
p
l
l
e
e
> wl_dual wds status
Please enable WDS hello function first.
> wl_dual wds hello 1
% <Note> Please restart router after you set the parameters.
