Draytek VigorAP 903 - I-2-5 Wall-Mount Connection

9
I-2-5 Wall-mount Connection
1. Drill two holes on the wall. The distance between the holes shall be 80mm. The recommended drill
diameter shall be 6.5mm (1/4”).
2. Fit screws into the wall using the appropriate type of wall plug.
3. Hang the VigorAP directly onto the screws.
Wall
