I-2 Hardware Installation
This section will guide you to install the VigorAP 903 through hardware connection and configure the
device’s settings through web browser.
Before starting to configure VigorAP 903, you have to connect your devices correctly.
I-2-1 Wired Connection for PC in LAN
1. Connect VigorAP 903 to ADSL modem, router, or switch/hub in your network through the LAN A
port of the access point by Ethernet cable.
2. Connect a computer to other available LAN A port. Make sure the subnet IP address of the PC is the
same as VigorAP 903 management IP, e.g., 192.168.1.X.
3. Connect the A/C power adapter to the wall socket, and then connect it to the PWR connector of the
access point.
4. Power on VigorAP 903.
5. Check all LEDs on the front panel. ACT LED should blink, LAN LEDs should be on if the access point
is correctly connected to the xDSL modem, router or switch/hub.
(For the detailed information of LED status, please refer to section I-1-1.)
