DSC Neo - PGM Attributes

Section 6: Programming Worksheets
[010] [000 - 164] PGM Attributes
[000] – Main Bell
Mask
Description on page 77
R 01 – Fire Alarm
R 02 – CO Alarm
R 03 – Burglary Alarm
R 04 – Flood Alarm
R 05 – Bell Squawks
001-164 PGM Attributes
PGM 1-164: 100 – Null PGM
101 – Fire and Burglary R 01 – True Output
102 – Delay Fire and Burg R 01 – True Output
103 – Sensor Reset [*][7][2] o 03 – Code Required
109 – Courtesy Pulse R 01 – True Output
111 – Keypad Buzzer Follow R 01 – True Output
o 02 – Timed Output
R 09 – Entry Delay
R 10 – Exit Delay
R 12 – Keypad Buzzer Zone
R 13 – Audible Exit Zone
R 14 – Auto-Arm Pre-Alert
114 – Ready To Arm R 01 – True Output
115 – Armed Status R 01 – True Output
116 – Armed Away Mode R 01 – True Output
117 – Armed Stay Mode R 01 – True Output
120 – Away Armed No
Bypass
R 01 – True Output
121 – Command Output 1 R 01 – True Output
o 02 – Timed Output
R 03 – Code Required
R Schedule 001
122 – Command Output 2 R 01 – True Output
o 02 – Timed Output
o 03 – Code Required
R Schedule 001
123 – Command Output 3 R 01 – True Output
o 02 – Timed Output
o 03 – Code Required
R Schedule 001
124 – Command Output 4 R 01 – True Output
o 02 – Timed Output
o 03 – Code Required
R Schedule 001
129 – Partition Status Alarm
Memory
R 01 – True Output
132 – Holdup Output R 01 – True Output
o 02 – Timed Output
- 136 -
