DSC Neo User Manual

Section 2: Installation
2.4.13 CO Detector
The following hardwired CO detector models can be used with PowerSeries Neo alarm controllers:
l Potter Model CO-12/24, UL File E321434
l Quantum Model 12-24SIR, UL File E186246
l NAPCO Model FW-CO12 or FW-CO1224, UL File E306780
l System Sensor Model CO1224, UL File E307195
Note: For multiple unit connections, the leads between CO detectors must be broken. The power supervision relay must be
powered from the last detector in the loop.
Wireless CO detectors are also available. When installing wireless CO detectors, use only model PG9913
UL
, PG8913,
PG4913. An HSM2HOSTx (x=9
UL
/8/4) wireless receiver or HS2LCDRF(P)x/HS2ICNRF(P)x (x=9
UL
/8/4) wireless keypad are
required when installing wireless CO detectors. For more details on these wireless devices, refer to their respective install-
ation manuals.
Note: Use only
UL
approved devices with UL/ULC listed systems.
Table 2-11 CO Detector Ratings
Device Description Max Rating @12VDC
CO-12/24 Potter model CO detector 40mA
12-24SIR Quantum model CO detector 75mA
FW-CO12
FW-CO1224
NAPCO model CO detector 90mA
CO1224 System Sensor model COdetector 40mA
Figure 2-17 CO Detector Wiring
- 26 -

DSC Neo Specifications

General

Model	DSC Neo
Category	Security System
Partitions	Up to 8
Type	Hybrid Security System
Zones	Up to 128 zones
Communication	Cellular, IP
Compatibility	PowerG wireless sensors
Remote Access	Yes, via app
PGMs	4
Wireless Range	Up to 2 km with PowerG
Event Buffer	1000 events
Wireless Frequency	433 MHz, 868 MHz
Power Supply	16.5VAC, 40VA
Battery Backup	Yes, 12VDC 7Ah
Operating Temperature	0°C to 49°C (32°F to 120°F)
Event Log	Yes
