DSC Neo User Manual

Section 1: Introduction
l User, partition, module, zone and system labels
l Programmable system loop response
l Keypad and panel software versions viewable through keypad
l Doorbell zone type
l Low battery PGM type
1.1.2 Available Models
The following alarm controller models are available:
l HS2016-4
l HS2016
l HS2032
l HS2064
l HS2128
Note: Not all models are available in all markets.
Model Differences
The table below lists the features of each alarm system model.
Table 1-1 Model Differences
Features HS2128 HS2064 HS2032 HS2016 HS2016-4
Hardwired zones 128 64 32 16 16
Onboard zone inputs 8 8 8 6 8
Wireless zones 128 64 32 16 32
Partitions 8 8 4 2 8
Users 95 95 72 48 48
Onboard outputs 4 4 2 2 4
Max outputs 148 80 38 22 24
Keypads 16 8 8 8 8
Wireless keys 32 32 32 16 16
Wireless sirens 16 8 8 4 4
Wireless repeaters * 8 8 8 4 4
Proximity tags 94 94 71 47 47
Alt Comm. phone #’s 4 4 4 4 4
User-programmable phone #’s 8 8 8 8 8
Event buffer 1000 500 500 500 500
8-zone expander HSM2108 15 7 3 1 1
Power supply HSM2300 4 3 3 3 3
Power supply/high-current output expander
HSM2204
4 3 1 1 1
8-output expander HSM2208 16 8 4 2 2
2- way wireless integration module 1 1 1 1 1
Audio verification module HSM2955 1 1 1 1 1
*For UL installations, 2 repeaters must be installed for proper signal routing.
- 8 -

DSC Neo Specifications

General

Model	DSC Neo
Category	Security System
Partitions	Up to 8
Type	Hybrid Security System
Zones	Up to 128 zones
Communication	Cellular, IP
Compatibility	PowerG wireless sensors
Remote Access	Yes, via app
PGMs	4
Wireless Range	Up to 2 km with PowerG
Event Buffer	1000 events
Wireless Frequency	433 MHz, 868 MHz
Power Supply	16.5VAC, 40VA
Battery Backup	Yes, 12VDC 7Ah
Operating Temperature	0°C to 49°C (32°F to 120°F)
Event Log	Yes
