- 192 -
Appendix 1: Reporting Codes
The following tables contain Contact ID and Automatic SIA format reporting codes. See "[308] Event Reporting" on page 100
for event reporting codes.
Contact ID
Each of the digits indicate specific information about the signal. For example, if zone 1 is an entry/exit point, the event code
contains [34]. The central station would receive the following:
*BURG - ENTRY/EXIT - 1 where the “1” indicates which zone went into alarm.
"Contact ID and SIAZone Alarm/Restore Event Codes" on page 192 for code definitions.
SIA Format - Level 2 (Hard Coded)
The SIA communication format used in this product follows the level 2 specifications of the SIA Digital Communication Stand-
ard - October 1997. This format sends the account code along with its data transmission. The transmission appears similar to
the following at the receiver:
N ri1 BA 01
N = New Event
ri1 = Partition /Area Identifier
BA = Burglary Alarm
01 = Zone 1
A system event uses the Area Identifier ri00.
Contact ID and SIAZone Alarm/Restore Event Codes
Section # Definition Dialer Dir-
ection*
Automatic Contact ID
Codes
SIA Auto Rep Codes**
Zone Events
[307] Zone Alarms A/R see "Contact ID & SIA Zone Alarm/Restore Event Codes" on
page 199" for details.
[307] Zone Restores A/R
[307] Zone tamper/restore MA/R E(3)83-ZZZ / R(3)83-ZZZ TA-ZZZ / TR-ZZZZ
[307] Zone fault/restore MA/R E(3)8A-ZZZ / R(3)8A-ZZZ UT-ZZZZ / UJ-ZZZZ
Tamper Events
[308]-[101] Keypad 1 tamper/restore alarm T/R E(3)83-601 / R(3)83-601 TA-0601 / TR-0601
[308]-[101] Keypad 2 tamper/restore alarm T/R E(3)83-602 / R(3)83-602 TA-0602 / TR-0602
[308]-[101] Keypad 3 tamper/restore alarm T/R E(3)83-603 / R(3)83-603 TA-0603 / TR-0603
[308]-[101] Keypad 4 tamper/restore alarm T/R E(3)83-604 / R(3)83-604 TA-0604 / TR-0604
[308]-[101] Keypad 5 tamper/restore alarm T/R E(3)83-605 / R(3)83-605 TA-0605 / TR-0605
[308]-[101] Keypad 6 tamper/restore alarm T/R E(3)83-606 / R(3)83-606 TA-0606 / TR-0606
[308]-[101] Keypad 7 tamper/restore alarm T/R E(3)83-607 / R(3)83-607 TA-0607 / TR-0607
[308]-[101] Keypad 8 tamper/restore alarm T/R E(3)83-608 / R(3)83-608 TA-0608 / TR-0608
[308]-[101] Keypad 9 tamper/restore alarm T/R E(3)83-609 / R(3)83-609 TA-0609 / TR-0609
[308]-[101] Keypad 10 tamper/restore alarm T/R E(3)83-610 / R(3)83-610 TA-0610 / TR-0610
[308]-[101] Keypad 11 tamper/restore alarm T/R E(3)83-611 / R(3)83-611 TA-0611 / TR-0611
[308]-[101] Keypad 12 tamper/restore alarm T/R E(3)83-612 / R(3)83-612 TA-0612 / TR-0612
[308]-[101] Keypad 13 tamper/restore alarm T/R E(3)83-613 / R(3)83-613 TA-0613 / TR-0613
[308]-[101] Keypad 14 tamper/restore alarm T/R E(3)83-614 / R(3)83-614 TA-0614 / TR-0614
[308]-[101] Keypad 15 tamper/restore alarm T/R E(3)83-615 / R(3)83-615 TA-0615 / TR-0615
[308]-[101] Keypad 16 tamper/restore alarm T/R E(3)83-616 / R(3)83-616 TA-0616 / TR-0616
[308]-[101] Siren 1 tamper/restore alarm T/R E (3)83-801 / R (3)83-801 TA-0801 / TR-0801
[308]-[101] Siren 2 tamper/restore alarm T/R E(3)83-802 / R (3)83-802 TA-0802 / TR-0802
[308]-[101] Siren 3 tamper/restore alarm T/R E(3)83-803 / R (3)83-803 TA-0803 / TR-0803
[308]-[101] Siren 4 tamper/restore alarm T/R E (3)83-804 / R (3)83-804 TA-0804 / TR-0804
[308]-[101] Siren 5 tamper/restore alarm T/R E(3)83-805 / R (3)83-805 TA-0805 / TR-0805
