DSC Neo User Manual

Section 6: Programming Worksheets
6.11 DLS Programming
[401] DLS/SA Options
1 – o Double Call
Description on page 113 2 – R User Enables DLS
3 – o DLS Callback
4 – o User Call up
6 – o Panel Call up and Baud Rate
7 – R Alt. Comm. DLS
[402] PSTN DLS Phone Number Programming
Description on page 113
(31-digit phone number; Default: DFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFF):
[403] DLS Access Code
Description on page 113
(6-digit hex; 000000-FFFFFF; Default: 212800):
[404] DLS/SA Panel ID
Description on page 113
(10-digit hex; 0000000000-FFFFFFFFFF; Default 2128000000):
[405] PSTN Double Call Timer
Description on page 114
(3-decimal; 000-255; Default: 060):
[406] PSTN Number of Rings to Answer On
Description on page 114
(3-decimal; 000-255; Default 000):
[407] SA Access Code
Description on page 114
(6-digit hex; 000000-FFFFFF; Default: FFFFFF):
[410] Automatic DLS Options
Description on page 114
001 – Auto DLS Options 1 – o Periodic DLS
3 – o DLS / Event Buffer 75% Full
8 – o DLS on Programming Change
002 – Periodic DLS Days (3-digit decimal; 000-255; Default: 000 days):
003 – Periodic DLS Time (4-digit decimal; HH:MM; 0000-2359; Default: 0000):
007 – Delay Call Window Start (4-digit decimal; 0000-2359;
HH:MM)
1 – 0000 Delay Call Window Start
Default: 0000 2 – 0000 Delay Call Window End
6.12 Virtual Inputs
[560] Virtual Inputs
- 166 -

DSC Neo Specifications

General

Model	DSC Neo
Category	Security System
Partitions	Up to 8
Type	Hybrid Security System
Zones	Up to 128 zones
Communication	Cellular, IP
Compatibility	PowerG wireless sensors
Remote Access	Yes, via app
PGMs	4
Wireless Range	Up to 2 km with PowerG
Event Buffer	1000 events
Wireless Frequency	433 MHz, 868 MHz
Power Supply	16.5VAC, 40VA
Battery Backup	Yes, 12VDC 7Ah
Operating Temperature	0°C to 49°C (32°F to 120°F)
Event Log	Yes
