DSC Neo User Manual

Section 2: Installation
Figure 2-4 HSM2108 Zone Expander
Refer to the HSM2108 installation sheet for more information.
2.4.2 Output Expander
The HSM2208 module is used to add up to 8 low-current programmable outputs to the alarm system.
The 4-wire Corbus connection is used by the panel to communicate with the module. Connect the RED, BLK, YEL and GRN
terminals to the Corbus terminals on the alarm panel. Board current draw: 40mA.
Figure 2-5 HSM2208 Output Expander
2.4.3 Wireless Transceiver Module
The HSM2HOSTx 2-way wireless integration module provides communication between wireless devices and the alarm con-
troller.
Connect the HSM2HOSTx to the 4-wire Corbus of the alarm controller according to the following diagram.
Figure 2-6 HSM2HOSTx Wiring Diagram
After you have completed the wiring, reconnect power to the security system. Board currant draw: 35mA
- 19 -

DSC Neo Specifications

General

Model	DSC Neo
Category	Security System
Partitions	Up to 8
Type	Hybrid Security System
Zones	Up to 128 zones
Communication	Cellular, IP
Compatibility	PowerG wireless sensors
Remote Access	Yes, via app
PGMs	4
Wireless Range	Up to 2 km with PowerG
Event Buffer	1000 events
Wireless Frequency	433 MHz, 868 MHz
Power Supply	16.5VAC, 40VA
Battery Backup	Yes, 12VDC 7Ah
Operating Temperature	0°C to 49°C (32°F to 120°F)
Event Log	Yes
