DSC Neo User Manual

Appendix 1: Reporting Codes
Section # Definition Dialer Dir-
ection*
Automatic Contact ID
Codes
SIA Auto Rep Codes**
[308]-[332] HSM2204 2 Low Battery trouble/restore MA/R E(3)A2-602
R(3)A2-602
YT-0602 / YR-0602
[308]-[332] HSM2204 3 Low Battery trouble/restore MA/R E(3)A2-603
R(3)A2-603
YT-0603 / YR-0603
[308]-[332] HSM2204 4 Low Battery trouble/restore MA/R E(3)A2-604
R(3)A2-604
YT-0604 / YR-0604
[308]-[332] HSM2300 1 Low Battery trouble/restore MA/R E(3)A2-621
R(3)A2-621
YT-0621 / YR-0621
[308]-[332] HSM2300 2 Low Battery trouble/restore MA/R E(3)A2-622
R(3)A2-622
YT-0622 / YR-0622
[308]-[332] HSM2300 3 Low Battery trouble/restore MA/R E(3)A2-623
R(3)A2-623
YT-0623 / YR-0623
[308]-[332] HSM2300 4 Low Battery trouble/restore MA/R E(3)A2-624
R(3)A2-624
YT-0624 / YR-0624
[308]-[332] HSM2204 1 Battery absent trouble/restore MA/R E(3)11-601
R(3)11-601
YM-0601 / YR-0601
[308]-[332] HSM2204 2 Battery absent trouble/restore MA/R E(3)11-602
R(3)11-602
YM-0602 / YR-0602
[308]-[332] HSM2204 3 Battery absent trouble/restore MA/R E(3)11-603
R(3)11-603
YM-0603 / YR-0603
[308]-[332] HSM2204 4 Battery absent trouble/restore MA/R E(3)11-604
R(3)11-604
YM-0604 / YR-0604
[308]-[332] HSM2300 1 Battery absent trouble/restore MA/R E(3)11-621
R(3)11-621
YM-0621 / YJ-0621
[308]-[332] HSM2300 2 Battery absent trouble/restore MA/R E(3)11-622
R(3)11-622
YM-0622 / YJ-0622
[308]-[332] HSM2300 3 Battery absent trouble/restore MA/R E(3)11-623
R(3)11-623
YM-0623 / YJ-0623
[308]-[332] HSM2300 4 Battery absent trouble/restore MA/R E(3)11-624
R(3)11-624
YM-0624 / YJ-0624
Alternate Communicator
[308]-[351] Alternate Communicator fault/restore MA/R E(3)3A-000
R(3)3A-000
ET-0000 / ER-0000
[308]-[351] Alternate Communicator Radio/SIM failure/restore MA/R E(3)AA-001
R(3)AA-001
YX-0001 / YK-0001
[308]-[351] Alternate Communicator cellular trouble/restore MA/R E(3)AA-001
R(3)AA-001
YX-0001 / YK-0001
[308]-[352] Alternate Communicator Ethernet trouble/restore MA/R E(3)AA-001
R(3)AA-001
YX-0001 / YK-0001
[308]-[354] Alternate Communicator Receiver 1 absent/restore MA/R E(3)5A-001
R(3)5A-001
YS-0001 / YK-0001
[308]-[354] Alternate Communicator Receiver 2 absent/restore MA/R E(3)5A-002
R(3)5A-002
YS-0002 / YZ-0002
[308]-[354] Alternate Communicator Receiver 3 absent/restore MA/R E(3)5A-003
R(3)5A-003
YS-0003 / YZ-0003
[308]-[354] Alternate Communicator Receiver 4 absent/restore MA/R E(3)5A-004
R(3)5A-004
YS-0004 / YZ-0004
[308]-[355] Alternate Communicator Receiver 1 Supervisory trouble/restore MA/R E(3)5A-001/R(3)5A-001 YS-0001 / YK-0001
- 196 -

DSC Neo Specifications

General

Model	DSC Neo
Category	Security System
Partitions	Up to 8
Type	Hybrid Security System
Zones	Up to 128 zones
Communication	Cellular, IP
Compatibility	PowerG wireless sensors
Remote Access	Yes, via app
PGMs	4
Wireless Range	Up to 2 km with PowerG
Event Buffer	1000 events
Wireless Frequency	433 MHz, 868 MHz
Power Supply	16.5VAC, 40VA
Battery Backup	Yes, 12VDC 7Ah
Operating Temperature	0°C to 49°C (32°F to 120°F)
Event Log	Yes
