DSC Neo User Manual

Section 6: Programming Worksheets
006 – Partition 8 No Activity Arming Timer (Default: 000):
007 – Partition 8 No Activity Arming Pre-Alert Timer (Default: 001):
[200] Partition Mask
001 – Partition 1 to 8 Enable Mask R – Partition 1
o – Partition 2
Descriptions on page 98 o – Partition 3
o – Partition 4
o – Partition 5
o – Partition 6
o – Partition 7
o – Partition 8
6.9 Partition and Zone Assignment
[201]-[208] Partition Zone Assignment
(Description on page 99)
[201] Partition 1 Zone Assignment [202] Partition 2 Zone Assignment
Bit 1 2 3 4 5 6 7 8 Bit 1 2 3 4 5 6 7 8
001 – 01-08
R R R R R R R R
001 – 01-08
o o o o o o o o
002 – 09-16
R R R R R R R R
002 – 09-16
o o o o o o o o
003 – 17-24
o o o o o o o o
003 – 17-24
o o o o o o o o
004 – 25-32
o o o o o o o o
004 – 25-32
o o o o o o o o
005 – 33-40
o o o o o o o o
005 – 33-40
o o o o o o o o
006 – 41-48
o o o o o o o o
006 – 41-48
o o o o o o o o
007 – 49-56
o o o o o o o o
007 – 49-56
o o o o o o o o
008 – 57-64
o o o o o o o o
008 – 57-64
o o o o o o o o
009 – 65-72
o o o o o o o o
009 – 65-72
o o o o o o o o
010 – 73-80
o o o o o o o o
010 – 73-80
o o o o o o o o
011 – 81-88
o o o o o o o o
011 – 81-88
o o o o o o o o
012 – 89-96
o o o o o o o o
012 – 89-96
o o o o o o o o
013 – 97-104
o o o o o o o o
013 – 97-104
o o o o o o o o
014 – 105-112
o o o o o o o o
014 – 105-112
o o o o o o o o
015 – 113-120
o o o o o o o o
015 – 113-120
o o o o o o o o
016 – 121-128
o o o o o o o o
016 – 121-128
o o o o o o o o
[203] Partition 3 Zone Assignment [204] Partition 4 Zone Assignment
Bit 1 2 3 4 5 6 7 8 Bit 1 2 3 4 5 6 7 8
001 – 01-08
o o o o o o o o
001 – 01-08
o o o o o o o o
002 – 09-16
o o o o o o o o
002 – 09-16
o o o o o o o o
003 – 17-24
o o o o o o o o
003 – 17-24
o o o o o o o o
004 – 25-32
o o o o o o o o
004 – 25-32
o o o o o o o o
- 154 -

DSC Neo Specifications

General

Model	DSC Neo
Category	Security System
Partitions	Up to 8
Type	Hybrid Security System
Zones	Up to 128 zones
Communication	Cellular, IP
Compatibility	PowerG wireless sensors
Remote Access	Yes, via app
PGMs	4
Wireless Range	Up to 2 km with PowerG
Event Buffer	1000 events
Wireless Frequency	433 MHz, 868 MHz
Power Supply	16.5VAC, 40VA
Battery Backup	Yes, 12VDC 7Ah
Operating Temperature	0°C to 49°C (32°F to 120°F)
Event Log	Yes
