DSC Neo User Manual

Section 6: Programming Worksheets
EN
R 6 – Access Code Required for [*][3]
o 7 – Access Code Required for [*][4]
EN
R 7 – Access Code Required for [*][4]
o 8 – [*][6] Accessibility Option
[024] System Options 12
Description on page 95
NA
o 1– 50Hz AC / 60 Hz AC
EN
R 1– 50Hz AC / 60 Hz AC
o 2 – Crystal Timebase
EN
R 2 – Crystal Timebase
o 3 – AC/DC Inhibits Arming
EN
R 3 – AC/DC Inhibits Arming
o 4 – Tampers Inhibit Arming
o 5 – Real Time Clock Option
o 6 – Not Used
o 7 – Not Used
o 8 – DLS Disconnect
[025] System Options 13
Description on page 96
o 1 – European Dial
R 2 – Force Dial
o 3 – Test Transmission Counter in Minutes
o 4 – Not Used
o 5 – ID Tone
o 6 – Tone Generated-2100Hz
o 7 – 1 Hour DLS Window
o 8 – FTC Audible Bell
[040] User Authentication
Description on page 97
R 1 – User Code or Prox. Tag
o 2 – User Code and Prox. Tag
[041] Access Code Digits
Description on page 97
R 00 – 4-Digit Access Codes
o 01 – 6-Digit Access Codes
- 149 -

DSC Neo Specifications

General

Model	DSC Neo
Category	Security System
Partitions	Up to 8
Type	Hybrid Security System
Zones	Up to 128 zones
Communication	Cellular, IP
Compatibility	PowerG wireless sensors
Remote Access	Yes, via app
PGMs	4
Wireless Range	Up to 2 km with PowerG
Event Buffer	1000 events
Wireless Frequency	433 MHz, 868 MHz
Power Supply	16.5VAC, 40VA
Battery Backup	Yes, 12VDC 7Ah
Operating Temperature	0°C to 49°C (32°F to 120°F)
Event Log	Yes
