Section 6: Programming Worksheets
00 - Null Key
02 - Instant Stay Arm
03 - Stay Arm
04 - Away Arm
05 - [*][9]No Entry Arm
06 - Chime On/Off
07 - System Test
09 - Night Arm
12 - Global Stay Arm
13 - Global Away Arm
14 - Global Disarming
16 - Quick Exit
17 - Arm Interior
21 - Command Output 1
22 - Command Output 2
23 - Command Output 3
24 - Command Output 4
29 - Bypass Group Recall
31 - Local PGM Active
32 - Bypass Mode
33 - Bypass Recall
34 - User Programming
35 - User Functions
37 - Time/Date Programming
39 - Trouble Display
40 - Alarm Memory
61 - Partition Select 1
62 - Partition Select 2
63 - Partition Select 3
64 - Partition Select 4
65 - Partition Select 5
66 - Partition Select 6
67 - Partition Select 7
68 - Partition Select 8
011 – Keypad I/O (Zone number or output number; 3-digit decimal; Default: 000):
012 – Local PGM Output Timer Pulse Time Minutes (Default: 00 minutes)
Pulse Time Seconds (Default: 05 seconds)
021 – Keypad Option 1
For systems compliant with EN50131-1
and EN50131-3 Section [021]: options
1 and 2 must be OFF.
1 – R [F] Key Enabled
1 – o [F] Key Enabled
2-digit decimal 2 – R [M] Key Enabled
3 – R [P] Key Enabled
4 – R Display Code or X’s
022 – Keypad Option 2 1 – R Local Clock Display
2 – o Local Clock 24-Hour
3 – R Auto Alarm Scroll
5 – o Power LED
6 – R Power LED AC Present
7 – R Alarms Displayed While Armed
8 – R Auto Scroll Open Zones
023 – Keypad Option 3 1 – o Armed LED Power Save
2 – R Keypad Status Shows Arm Mode
3 – o 5th Terminal is PGM Output/Zone Input
7 – o Local Display of Temperature
8 – o Low Temperature Warning
030 – LCD Message:
031 – Downloaded LCD Message Duration (3-digit decimal; 000-255; Default: 000):
041 – Indoor Temperature Zone Entry (3-digit decimal; 000-128; Default: 000):
042 – Outdoor Temperature Zone Entry (3-digit decimal; 000-128; Default: 000):
101-228 – Door Chime Sound: 00 – o Disabled
01 – R 6 Beeps
02 – o Bing Bong
- 179 -
To Next Page
