DSC Neo User Manual

Appendix 1: Reporting Codes
Section # Definition Dialer Dir-
ection*
Automatic Contact ID
Codes
SIA Auto Rep Codes**
[308]-[101] HSM2208: 8-Output Expander module #12 tamper/restored T/R E(3)41-212 / R(3)41-212 ES-0212 / EJ-0212
[308]-[101] HSM2208: 8-Output Expander module #13 tamper/restored T/R E(3)41-213 / R(3)41-213 ES-0213 / EJ-0213
[308]-[101] HSM2208: 8-Output Expander module #14 tamper/restored T/R E(3)41-214 / R(3)41-214 ES-0214 / EJ-0214
[308]-[101] HSM2208: 8-Output Expander module #15 tamper/restored T/R E(3)41-215 / R(3)41-215 ES-0215 / EJ-0215
[308]-[101] HSM2208: 8-Output Expander module #16 tamper/restored T/R E(3)41-216 / R(3)41-216 ES-0216 / EJ-0216
[308]-[101] HSM2204: Power Supply-1A (4 high-current outputs) #1 tamper-
/restored
T/R E(3)41-601 / R(3)41-601 ES-0601 / EJ-0601
[308]-[101] HSM2204: Power Supply-1A (4 high-current outputs) #2 tamper-
/restored
T/R E(3)41-602 / R(3)41-602 ES-0602 / EJ-0602
[308]-[101] HSM2204: Power Supply-1A (4 high-current outputs) #3 tamper-
/restored
T/R E(3)41-603 / R(3)41-603 ES-0603 / EJ-0603
[308]-[101] HSM2204: Power Supply-1A (4 high-current outputs) #4 tamper-
/restored
T/R E(3)41-604 / R(3)41-604 ES-0604 / EJ-0604
[308]-[101] HSM2300: Power Supply module #1 tamper/restored T/R E(3)41-621 / R(3)41-621 ES-0621 / EJ-0621
[308]-[101] HSM2300: Power Supply module #2 tamper/restored T/R E(3)41-622 / R(3)41-622 ES-0622 / EJ-0622
[308]-[101] HSM2300: Power Supply module #3 tamper/restored T/R E(3)41-623 / R(3)41-623 ES-0623 / EJ-0623
[308]-[101] HSM2300: Power Supply module #4 tamper/restored T/R E(3)41-624 / R(3)41-624 ES-0624 / EJ-0624
[308]-[101] HSM2955: Audio module tamper/restore T/R E(3)41-553 / R(3)41-553 ES-0553 / EJ-0553
[308]-[101] Alternate Communicator Tamper (only on supported models)
T/R
E(3)41-950 / R(3)41-950 ES-0950 / EJ-0950
[308]-[101] Keypad Lockout - Incorrect access code entry T/R E(4)61-000 / R(4)61-000 JA-0000
Opening Events
[308]-[201] User Openings - Disarmed by user O/C E(4)A1-UUU OP-UUUU
[308]-[202] Automatic Arming Canceled O/C E(4)64-UUU CI-0000
[308]-[201] Special Opening - System disarmed using: keyswitch, main-
tenance code, DLS software, wireless key
O/C E(4)AA-000 OP-0000
[308]-[211] Late to Open - System not disarmed before late to open time
expired
O/C E(4)53-000 CT-0000
[308]-[202] Automatic (Schedule) Opening O/C E(4)A3-000 OA-0000
[308]-[201] Keyswitch Open O/C E(4)A9-ZZZ OS-ZZZZ
Closing Events
[308]-[201] User Closings - System armed by user, wireless key O/C R(4)A1-UUU CL-UUUU
[308]-[221] Partial Closing - 1 or more zones bypassed when armed O/C E(4)56-000 CG-0000
[308]-[201] Special Closing - System armed via: quick arm, keyswitch, func-
tion key, maintenance code, DLS software
O/C R(4)AA-000 CL-0000
[308]-[211] Late to Close - Auto-arm prealert sounded O/C E(4)54-000 CI-0000
[308]-[211] Exit Fault O/C E(3)74-ZZZ EA-ZZZZ
[308]-[202] Automatic (Schedule) Closing O/C R (4)A3-000 CA-0000
[308]-[201] Keyswitch Close O/C R(4)A9-ZZZ CS-ZZZZ
System Trouble Events
[308]-[301] Battery trouble/restore - Main panel MA/R E(3)A2-000 / R(3)A2-000 YT-0000 / YR-0000
[308]-[301] Battery absent trouble/restore - Main panel MA/R E(3)11-000 / R(3)11-000 YM-0000 / YR-0000
[308]-[301] Panel AC trouble/restore - Main panel MA/R E(3)A1-000 / R(3)A1-000 AT-0000 / AR-0000
[308]-[302] Bell Circuit trouble/restore MA/R E(3)21-000 / R(3)21-000 YA-9999 / YH-9999
[308]-[302] TLM (telephone line) fail/restore MA/R E(3)51-000 / R(3) 51-000 LT-0001 / LR-0001
[308]-[302] Auxiliary Power trouble/restore MA/R E(3) 12-000 / R(3) 12-000 YP-0000 / YQ-0000
- 194 -

DSC Neo Specifications

General

Model	DSC Neo
Category	Security System
Partitions	Up to 8
Type	Hybrid Security System
Zones	Up to 128 zones
Communication	Cellular, IP
Compatibility	PowerG wireless sensors
Remote Access	Yes, via app
PGMs	4
Wireless Range	Up to 2 km with PowerG
Event Buffer	1000 events
Wireless Frequency	433 MHz, 868 MHz
Power Supply	16.5VAC, 40VA
Battery Backup	Yes, 12VDC 7Ah
Operating Temperature	0°C to 49°C (32°F to 120°F)
Event Log	Yes
