3-12
Chapter 3 Advanced Operation
3-5. Registering the folding value directly while processing
The current folding settings can be registered for later reference when performing operations under the
same conditions.
Test fold or perform folding process, check folding misalignment, and ne-adjust when registering the value.
1
Press the menu key to display the [Irreg Set] screen.
Irreg Set
01
P Length
Fold1
Fold2
2
Input the registration number on the
keypad or the
key.
3
Press and hold the custom folding key.
A buzzer sounds “pii”, and the data will be registered.
4
Press the key.
Returns to the top screen.
4. Cross Fold
Cross fold is folding single-folded paper again as shown in the gure.
The upper limit of paper thickness is 127.9 g/m
2
/34 lb for ne quality paper and 157 g/m
2
/40 lb for coated
paper (cross fold only).
Rough paper may be thin and imsy, and therefore inappropriate for cross fold.
∑ dent
Paper Σ dent and folding misalignment
in both directions may increase or paper
may be fed unstably depending on the
following conditions. However, it is not a
malfunction.
- The folded line of single-folded paper
is not folded properly.
- Using environment (temperature and
humidity)
- Paper thickness, paper size, paper
type, or paper grain direction, etc.
Double-feed detection does not operate when cross fold is performed. Select the setting
[OFF].
