Chapter 4 Cleaning the Unit
3.
C
lean
in
g
the
be
lt
Suction b
elt
Sensor lever
Wipe the belt with a cloth moistened
with alcohol while rota
ting it by hand
.
Make sure tha
t the cloth does not get
caught on the sensor lev
er
.
Stack
er belt
1
Remov
e the auxiliary paper ejec
tion
guide.
2
W
ipe the stacker belt with a cloth
moistened with alcohol while r
otating it
by hand.
