6-1
Chapter 6 Appendix
Chapter 6 Appendix
Specifications
Depending on the system conguration, the specication may vary. Ask your dealer for details.
Model DF-1200
Type Desktop-type
Paper feed method Fan motor belt suction method
Paper size Length 182 to 457.2 mm/7.17 to 18 inches
Width 120 to 311 mm/4.73 to 12.24 inches
Regular size A3, A4, A5, B4, B5, B6/LGR, LGL, LTR, INV, STMT
Paper quality Fine quality paper, Recycled paper, Drawing paper : 52.3 to 157 g/m
2
/14 to 40 lb
Art paper, Coated paper : 73.3 to 157 g/m
2
/19 to 40 lb
* The processing speed is limited for coated paper of 104.7 g/m
2
/28 lb or less and
ne quality paper of 81.4 g/m
2
/22 lb or less.
Folding mode Single fold, Double fold, Irregular accordion fold, Letter fold, Accordion fold,
Brochure fold, Specic cross fold, Custom fold.
* Available custom fold modes are limited depending on paper type and size.
* For cross fold, the paper quality, paper size, ream weight and processing speed (3
or less) are limited.
Number of custom folding
registration memories
20
Stacking amount
for feeding paper
Sheet paper 50 mm/1.96 inches or less
Fine quality paper: 64 g/m
2
/17 lb, 625 sheets
81.4 g/m
2
/21.6 lb, 490 sheets
Art or coated paper 104.7 g/m
2
/21.82 lb, 560 sheets
Single folded paper
25 mm/0.98 inch or less
Processing speed (Max.) 260 sheets/minute
(A4 ne quality paper 81.4 g/m
2
/21.6 lb, single fold, processing speed 6, feed interval fast)
Additional functions • Test folding • Standard folding registration
• Custom folding registration • Entire paper length input mode
• Folding stopper xed • Refold function
• Ejection interval function Thin paper mode
• Force eject function • Force eject inside folding plate
• LCD display energy-saving • Power still ON alert
• Paper feed interval adjusting function • Idling function
Separating air output adjustment mode
• Cross fold mode
Paper ejection volume setting function
Paper feed tray descent distance setting function
Error detection functions • No paper detection • Paper jamming detection
• Miss-feed detection
Double feed detection (Limited paper quality, size, setting)
• Paper size error
Other detection functions
• In-machine jamming • Ejection section jamming
• Folding plate 1 set error Top cover open
• Folding plate 2 set error • Paper feed tray stuck prevention detection
• Paper feed pick up limit breakdown prevention detection
Airborne noise Equivalent continuous A-weighted sound pressure level: 74.3 dB
Sound pressure level: 94.3 dB
Put this machine on the table and measure at the place where it is 1 m/
39.37 inches from the control panel and 1.5 m/59.05 inches from the oor.
Power supply AC100 to 240 V 50/60 Hz
Current consumption 175 W (SIDE AIR KIT disconnected: 130 W)
1.8 to 0.7 A (SIDE AIR KIT disconnected: 1.3 to 0.6 A)
Dimensions
When in use: 1193(W) x 587(D) x 541(H) mm/46.97(W) x 23.11(D) x 21.30(H) inches
When in stored: 806(W) x 587(D) x 541(H) mm/31.73(W) x 23.11(D) x 21.30(H) inches
Mass (Weight) 65.5 kg/144.4 lb (Including accessories)
Option SIDE AIR KIT
