Programming

Service Instructions 755 A/756 A - 00.0 - 02/2019 309

Setting correction light barrier seam begin./end

 The display switches to Correction light barrier seam

begin./end.

Fig. 291: Set correction light barrier seam begin./end

Information

The arrows in the left half of the display indicate the correction direction:

Seam beginning

Correction outward

Correction inward

Seam end

Correction outward

Correction inward
