Programming

Service Instructions 755 A/756 A - 00.0 - 02/2019 311

Activating marking lamps 1 - 16

Fig. 293: Activate marking lamps 1-16

To activate the marking lamps:

1. Press the button of the desired marking lamp.

 The marking lamp is (de)activated.

Symbols Meaning

Marking lamp activated

Marking lamp deactivated
