Programming

Service Instructions 755 A/756 A - 00.0 - 02/2019 339

Select downholder mode

Information

Downholder, vacuum and waistband clamp must be activated in the

machine configuration ( p. 348).

 The display switches to Select downholder mode.

Fig. 318: Select downholder mode

Symbols Meaning

1: Downholder + waistband clamp

2: Vacuum

1: Downholder + vacuum

2: Waistband clamp

1: Downholder

2: Vacuum

3: Waistband clamp

1: Downholder + vacuum

Waistband clamp off

1: Downholder

2: Waistband clamp

3: Vacuum

Default Chapter3
