Programming

354 Service Instructions 755 A/756 A - 00.0 - 02/2019

Pedal operation

 The display switches to Pedal operation.

Fig. 327: Pedal operation

To set the pedal operation:

Press the desired button.

Symbol Meaning

Operation with 1 pedal

Operation with 2 pedals

•1

pedal right (function pedal)

•2

pedal left

• not active in 755 A/756 A

Operation with 2 pedals

•1

pedal left (function pedal)

•2

pedal right

• not active in 755 A/756 A
