Programming

390 Service Instructions 755 A/756 A - 00.0 - 02/2019

Set and test middle knife

 The display switches to Test middle knife.

Fig. 356: Test middle knife

To test the middle knife:

1. Press the button.

 Reference run is carried out.

2. Press the desired button.

Symbol Meaning

Adjust middle knife  p. 391

Middle knife On/Off

Step motor On/Off

Move middle knife to lower position (cutting position)  p. 392

Move to height of stroke  p. 392

Move middle knife to upper position  p. 392

Reference
