3.4 Removing the covers
For many types of setting work, you will have to remove the machine covers
first in order to access the components.
This chapter describes how to remove and then refit the individual covers.
The text for each type of setting work then specifies only the cover that
needs to be removed at that particular time.
3.4.1 Access to the underside of the machine
Cover
In order to access the components on the underside of the machine, you
must first swivel up the machine head.
WARNING
Risk of injury from moving parts!
Crushing possible.
Move the machine to the service position or switch
the machine off before removing the covers.
WARNING
Risk of injury from sharp parts!
Punctures possible.
Move the machine to the service position or switch
the machine off before removing the covers.
