Working basis
Service Instructions 867-M PREMIUM - 02.0 - 02/2017 17
Fig. 5: Access to the underside of the machine
Tilting the machine head
To tilt the machine head:
1. Tilt the machine head as far as it will go.
Erecting the machine head
To erect the machine head:
1. Erect the machine head.
3.4.2 Removing and placing the arm cover
Fig. 6: Removing and placing the arm cover
(1) - Arm cover (2) - Screws
