6.1 TERMINAL ASSIGNMENTS
1. RTD or T/C+
3. RTD, T/C- or Linear - Secondary Input (Optional)
4. Linear + or RTD compensation
12. Strain Gage Signal + or Linear +
13. Strain Gage Signal - or Linear -
14. Calibration 2 Primary Input
16. Excitation +
17. Excitation -, Calibration 1
21. Main Output mA/V +
22. Main Output mA/V -
23. Remote Reset
24. Remote Reset
45. Alarm 1. NO
46. Alarm 1, Common
47. Alarm 1. NC
48. Alarm 2, NO
49. Alarm 2. Common
50. Alarm 2, NC
51. Alarm 3, Common OPTIONAL
52. Alarm 3. NC/NO
53. 100-240 VAC OR 24 VAC OR 24 VDC (Polarity need not be observed)
54. LN LN 24 VDC
55. Protective Ground Protective Ground N/A
56. Secondary Output, mA/V +
OPTIONAL
57. Secondary Output. mA/V -
58. 24 VDC Auxiliary Power Supply +
OPTIONAL
59. 24 VDC Auxiliary Power Supply -
60. RS-485: A/A’
61. RS-485: B/B’ OPTIONAL
62. RS-485: Common
