5. If the values do not correspond with the values in the Calibration Parameters Summary Table
below, use the ▼ or ▲ keys to correct the value displayed.
6. When all the appropriate values are correct, set the dipswitches to operating mode.
CALIBRATION PARAMETERS SUMMARY
Parameter Circuit Input Type Range Value Note
CAL UPR (1)
PL.020 Primary Input Current Zero 0 mA
PH.020 Primary Input Current Full scale 20 mA
P.020 Primary Input Current Verify (2)
PL.05 Primary Input Voltage 0-5V Zero 0 V
PH.05 Primary Input Voltage 0-5V Full scale 5 V
P.05 Primary Input Voltage 0-5V Verify (2)
PL.010 Primary Input Voltage 0-10V Zero 0 V
PH.010 Primary Input Voltage 0-10V Full scale 10 V
P.010 Primary Input Voltage 0-10V Verify (2)
SL.020 Secondary Input Current Zero 0 mA
SH.020 Secondary Input Current Full scale 20 mA
S.020 Secondary Input Current Verify (2)
SL.010 Secondary Input Voltage Zero 0 V
SH.010 Secondary Input Voltage Full scale 10 V
S.010 Secondary Input Voltage Verify (2)
SL.TC Secondary Input Thermocouple Zero 0 mV
SH.TC Secondary Input Thermocouple Full scale 50 mV
S.TC Secondary Input Thermocouple Verify (2)
S*RJ Secondary Input Thermocouple Ref. junct. Ambient
S.RJ Secondary Input Thermocouple Verify Ambient
SL.RTD Secondary Input RTD Zero 0 Ohm (2)
SH.RTD Secondary Input RTD Full scale 320 Ohm
S.RTD Secondary Input RTD Verify (2)
ML.CUR Main analog output Current Zero -5 mA
MH.CUR Main analog output Current Full Scale 25 mA
M.CUR Main analog output Current Verify (3)
ML.VOL Main analog output Voltage Zero -12.5 V
MH.VOL Main analog output Voltage Full scale 12.5V
M.VOL Main analog output Voltage Verify (3)
SL.CUR Second analog output Current Zero -5 mA
SH.CUR Second analog output Current Full scale 25 mA
S.CUR Second analog output Current Verify (3)
SL.VOL Second analog output Voltage Zero -12.5 V
SH.VOL Second analog output Voltage Full scale 12.5 V
S.VOL Second analog output Voltage Verify (3)
DEFLT Load default calibration DO NOT ATTEMPT TO MODIFY
and code UNDER ANY CIRCUMSTANCES
