DynoWare RT Upgrade for Model 424x Dynamometers Installation Guide
3-24
25 Connect the IR temperature sensor cable to the terminal block on the cable
adapter (G). Attach the wires to the terminal with the corresponding wire colors.
Route and attach the IR temperature sensor cable adapter to the eddy current
brake driver.
Note: The remaining two wires (green and silver/shield) are unused and left
disconnected.
26 Attach the cable adapter (H) to the load cell cable and route this cable to the eddy
current brake driver. Attach the load cell cable adapter to the eddy current brake
driver.
27 Connect the controller cable (N) to each eddy current brake driver. This cable was
unplugged from the theta controller.
28 Connect the power cable (O) to each eddy current brake driver. This cable was
unplugged from the theta controller.
29 Connect the power cable (A) to the DynoWare RT module. Plug the power cable
into your power source.
30 Connect the primary/secondary pickup cable (E) to the DynoWare RT module.
31 Reconnect your air hoses if removed. Be sure to connect the air hoses in the same
positions.
32 Connect the network cable (B) from your network to the DynoWare RT module.
Refer to “Network Connections” on page 1-6 for more information.
