CHAPTER 4
Loading the Vehicle
DynoWare RT Upgrade for Model 424x Dynamometers Installation Guide
4-4
9 Attach the tie-down straps.
Rear Wheel Drive
• Attach two tie-down straps from secure anchor points to the rear of the vehicle.
Attach additional tie-down straps from the rear of the vehicle as shown in
Figure 4-2.
• Attach two tie-down straps from secure anchor points to the front of the
vehicle.
Front Wheel Drive
• Attach two tie-down straps from secure anchor points to the rear of the vehicle.
• Attach two tie-down straps from secure anchor points to the front of the
vehicle. Attach additional tie-down straps across the front of the vehicle to
form a crisscross.
With front wheel drive vehicles, always use longitudinal and cross straps
at the front of the vehicle.
Four Wheel (All-Wheel) Drive
• Attach two tie-down straps from secure anchor points to the rear of the vehicle.
Attach additional tie-down straps across the rear of the vehicle to form a
crisscross.
• Attach two tie-down straps from secure anchor points to the front of the
vehicle. Attach additional tie-down straps across the front of the vehicle to
form a crisscross.
With four wheel drive vehicles, always use longitudinal and cross straps
at the front of the vehicle.
Figure 4-2: Attach the Tie-down Straps
rear wheel drive
front wheel drive
four wheel drive
