Eaton NZM3 User Manual

DMI
62
11/04 MN01219002Z-EN
DMI Status
This submenu is used to interrogate the current status of the
DMI.
COM
OK/Err indicates whether communication with the circuit-
breaker is running or is faulty.
SW Version
This parameter shows the version of the DMI firmware.
The latest firmware versions can be installed using the PC
software for the DMI. The latest versions are available on the
Internet at:
http://www.eaton.com/moeller
￫ Support
Diagnostics
Selecting the Diagnostics submenu will switch the circuit-
breaker to Diagnostics mode.
In this mode, current process data from the circuit-breaker is
not available. However, you can interrogate the status of the
circuit-breaker at previous events. Up to ten events can be
stored. Furthermore, the currently set parameters can also
be presented for the sake of comparison.
Statistical data can be called up in the “Operate hrs” and
“Operations” submenus.
DMI STATUS
Com
SW Version
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Eaton NZM3 Specifications

General

Rated voltage	690V AC
Type	Molded Case Circuit Breaker
Trip unit	Electronic or Thermal-Magnetic
Number of poles	3 or 4 poles
Standards	IEC 60947-2
Rated current	250 A, 300 A, 400 A, 500 A, 630 A
