Eaton NZM3 User Manual

NZM-XDMI-DPV1
(PROFIBUS-DPV1 Interface for
DMI)
96
11/04 MN01219002Z-EN
Table 11: Address assignment of the module 3 data inputs
Data position Designation
Octet 1
Bit 0 and Bit 1 Circuit-breaker position
Bit 2 and Bit 3 Circuit-breaker state
Bit 4 Ready to switch on
Bit 5 and Bit 6 Not used
Bit 7 Overload warning
Octet 2
Bit 0 Not used
Bit 1 General warning
Bit 2 Not used
Bit 3
Input 0
Bit 4 to Bit 6 Trip cause (Release reason)
Bit 7 Load rejection prewarning
Octet 3
Bit 0 Input 1
Bit 1 Input 2
Bit 2 Input 3
Bit 3 Input 4
Bit 4 Input 5
Bit 5 to Bit 7 Not used
Octet 4
Bit 0 Not used
Bit 1
Motor state
Bit 2 and Bit 3 Not used
Bit 4
Motor “ON” or motor anticlockwise rotation
Bit 5 Motor clockwise rotation
Bit 6 Star configuration
Bit 7 Delta configuration
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Eaton NZM3 Specifications

General

Rated voltage	690V AC
Type	Molded Case Circuit Breaker
Trip unit	Electronic or Thermal-Magnetic
Number of poles	3 or 4 poles
Standards	IEC 60947-2
Rated current	250 A, 300 A, 400 A, 500 A, 630 A
