Eaton Static Transfer Switch 2000A 3-Pole Installation and Operation Manual 164001127—Rev 01 17
CChhaapptteerr 33 IInnssttaallllaattiioonn PPllaannnniinngg
This chapter has planning information for the 3-pole STS 2000A. Additional specifications and planning
information can be found in the following:
• Chapter 6 Customer Communications Connections
• GUIDE SPECIFICATION Eaton PDI 2000 Amp 3-Pole Static Transfer Switch
33..11 SSyysstteemm EEnncclloossuurree
The STS 2000A enclosure is designed for the data center or telecommunications environment. The enclosure is
shown in Figure 1 , and enclosure details are listed below.
• NEMA-1 rated
• Dimensions: 90"W x 60"D x 84"H
• Enclosure is primed and painted with suitable semi-gloss enamel both inside and out. The Color is Pearl
White with black top venting.
• Large cable entry/exit openings top and bottom:
– Top entry: 33.75" x 29.00"
– Bottom entry: 37.50" x 25.50"
• STS weight is approximately 5400 lbs.
33..22 CClleeaarraanncceess aanndd SSeerrvviiccee AAcccceessss
• Ventilation clearances required:
– 6" both sides
– 24" overhead
• Service clearances required:
– 30" front and rear service clearance
– Front and rear access is required for installation and maintenance.
– All input and output power connections must be made from rear of the unit.
• For ease of servicing:
– All control and logic components are mounted separately from the power components.
– All MCCBs and MCSWs are draw-out type for ease of replacement.
33..33 CCoooolliinngg
The STS uses forced air cooling and rejects heat through removed protected openings in the top and bottom of
all modules.
33..44 EEnnvviirroonnmmeennttaall SSppeecciiffiiccaattiioonnss
• Storage temperature range: -40° to +80°C
• Storage Altitude: Up to 40,000 feet above sea level
• Operating temperature range: 0° to 40°C
• Operating altitude:
