60 Eaton Static Transfer Switch 2000A 3-Pole Installation and Operation Manual 164001127—Rev 01
The Ethernet Settings panel in the Settings screen (Figure 23) allows the operator to set an IP address if a
different address than the DHCP address is required.
• Address is the Ethernet IP address of the Switch, which can be set directly or by DHCP.
– If the Use DHCP has a green check mark (√), the DHCP address will be used for the IP address in
Address.
– If the Use DHCP icon has a red X, DHCP is not used to set the IP address. Enter an IP address in
Address for the Switch.
• Press Mask to enter Ethernet IP mask address.
• Press Gateway to enter Ethernet Gateway.
• MAC ID is set in the factory and cannot be changed.
• Toggle Use DHCP button:
– Green check mark: Use DHCP to assign IP address.
– Red X: Do not use DHCP; use Address IP value.
• Stat button: shows communications statistics (a service function)
• Restart button: restarts the Monitor. On the ROI, the Mode of Operation must be set to Redundant so
that there is a backup transfer process during the restart.
NOTE The Monitor must be restarted when Ethernet Settings change.
1111..33 TTiimmee SSeettttiinnggss
Time stamps are important data for log entries and alarms. The STS clock should be synchronized with clocks
in other equipment to accurately diagnose problems affecting multiple systems. You can set the STS clock
manually or with the Time Synchronization feature.
1111..33..11 MMaannuuaall TTiimmee SSeettttiinngg
To manually set the clock, enter a date and time in Time Settings on the Settings screen.
Press the Set button, which will bring up the Keyboard Screen. Enter time and date.
1111..33..22 TTiimmee SSyynncchhrroonniizzaattiioonn SSeettttiinnggss SSccrreeeenn ((SSNNTTPP))
The Time Synchronization feature with SNTP requires the STS Ethernet connection.
Prerequisites:
1. 1.The Ethernet Settings on the Settings screen must be configured.
2. The Ethernet port must be connected to a network with a reachable time server supporting SNTP.
3. You must have the IP address of the time server. The time server could be a dedicated timeserver possibly
with a GPS receiver, a local computer running time server software, or a timeserver on the Internet. You
should preferably use a local time server. All equipment related to the STS should use the same time
server if they have access.
System Setup: Networking
