● Printhead still wet after cleaning:
Allow the print head to fully dry before starting the jet.
● Debris or fibers creating a discharge path:
Clean the print head and check for fibers.
9.3.4 2.02 Charge
This failure occurs when the jet is being started, or when it is running.
Possible causes
● Blocked nozzle or misaligned jet:
Carry out the nozzle clear procedure described in the Troubleshooting section of this manual (see
“troubleshooting - Clearing the Print head Nozzle”).
● Print head code or modulation values set incorrectly:
Check the Print head and Modulation (MOD) values printed on the print head serial number label found
on the conduit, with the stored values. (see “Changing the System Setup”).
9.3.5 2.03 Velocity Of Drop
This failure may occur when the jet is being started.
Possible causes
● Misaligned jet:
Carry out the nozzle clear procedure described in the Troubleshooting section of this manual. (see
“Troubleshooting - Clearing the Print head Nozzle”).
● Print head code or modulation values set incorrectly:
Check the Print head and Modulation values printed on the print head serial number label found on the
conduit, with the stored values. (see “Changing the System Setup”).
● Build-up of ink on the sensors:
Clean the print head.
● Blocked filter:
Contact your local EC-JET distributor for assistance.
9.3.6 2.04 300V Power Supply
Possible cause
● The 300 Volt power supply output is out of tolerance or has failed:
Call your local EC-JET distributor.
9.3.7 2.05 Temperature/Deflector
A failure has occurred which the printer has not been able to fully identify (see Print Failures “2.00” and
“2.01”).
9.3.8 2.06 Ink Tank Empty
This failure occurs when the ink level sensor has been indicating low for a predetermined time:
