Menu structure UA 300 D Controller type UA 111 XP
70
Version 2.03 27. Juni 2008
S Screen 2−2−1 Zone 1
DEFROST 1 POS: XXXXX Entry Default
Def. End. Tmp. XX °C Defrost termination temperature setpoint −−, 5..20 8 °C
S Screen 2−2−2 Zone 2
DEFROST 2 POS: XXXXX Entry Default
Def. End. Tmp. XX °C Defrost termination temperature setpoint −−, 5..20 5 °C
S Screen 2−2−3 Zone 1A Altern.
DEFROST 1A POS: XXXXX Entry Default
Def. End. Tmp. XX °C Defrost termination temperature setpoint −−, 5..20 8 °C
S Screen 2−2−4 Zone 2A Altern.
DEFROST 2A POS: XXXXX Entry Default
Def. End. Tmp. XX °C Defrost termination temperature setpoint −−, 5..20 5 °C
S Screen 2−3 Not used with this controller type.
S Screen 2−4 Alarm
ALARM POS: XXXXX
1 Zone 1 Continue to Screen 2−4−1
2 Zone 2 Continue to Screen 2−4−2; shown only when two−zone operation is set (Screen 6−1)
3 Zone 1A Altern. Continue to Screen 2−4−3; shown only when setpoint toggle is enabled (Screen 3−3)
4 Zone 2A Altern. Continue to Screen 2−4−4; shown only when two−zone operation is set (Screen 6−1) and only
when setpoint toggle is enabled (Screen 3−3)
S Screen 2−4−1 Zone 1
ALARM 1 POS: XXXXX Entry Default
High Temp Setp XX °C High temperature setpoint at which High Temperature
alarm is generated
−30..30 8 °C
Low Temp Setp. XX K Low temperature setpoint (difference below temperature
control setpoint) at which Low Temperature alarm is gene-
rated
−−, 0..6 −−− K
