Menu structure UA 300 D Controller type UA 111 XP
71
E 2007 − ECKELMANN | BERLINER STRASSE 161 | 65205 WIESBADEN | FON +49(0)611 7103-0 | FAX 49(0)611 7103-133 | eckelmann.de
Version 2.03 27. Juni 2008
S Screen 2−4−2 Zone 2
ALARM 2 POS: XXXXX Entry Default
High Temp Setp XX °C High temperature setpoint at which High Temperature
alarm is generated
−30..30 8 °C
Low Temp Setp. XX K Low temperature setpoint (difference below temperature
control setpoint) at which Low Temperature alarm is gene-
rated
−−, 0..6 2 K
S Screen 2−4−3 Zone 1A Altern.
ALARM 1A POS: XXXXX Entry Default
High Temp Setp XX °C High temperature setpoint at which High Temperature
alarm is generated
−30..30 8 °C
Low Temp Setp. XX K Low temperature setpoint (difference below temperature
control setpoint) at which Low Temperature alarm is gene-
rated
−−, 0..6 2 K
S Screen 2−4−4 Zone 2A Altern.
ALARM 2A POS: XXXXX Entry Default
High Temp Setp XX °C High temperature setpoint at which High Temperature
alarm is generated
−30..30 8 °C
Low Temp Setp. XX K Low temperature setpoint (difference below temperature
control setpoint) at which Low Temperature alarm is gene-
rated
−−, 0..6 2 K
S Screen 2−5 Compressor
COMPRESSOR POS: XXXXX
1 Setpoints Continue to Screen 2−5−1, Setpoints
2 Setpoint toogle Continue to Screen 2−5−2, Setpoint Toggle
