Menu structure UA 300 D Controller type UA 111 XP
72
Version 2.03 27. Juni 2008
S Screen 2−5−1 Setpoints (Compressor)
COMPRESSOR POS: XXXXX Entry Default
Enable C1 XXX Enable Compressor 1 ↑, ↓,
(ON/OFF)
ON
Enable C2 xxx Enable Compressor 2 ↑, ↓,
(ON/OFF)
ON
Enable C3 xxx Enable Compressor 3 ↑, ↓,
(ON/OFF)
OFF
Delay C1 ON xxx s Start delay Compressor 1 0..250 60s
Delay C2 ON xxx s Start delay Compressor 2 0..250 180s
Delay C3 ON xxx s Start delay Compressors 3 0..250 10s
Delay C1 OFF xxx s Stop delay Compressor 1 0..250 60s
Delay C2 OFF xxx s Stop delay Compressor 2 0..250 15s
Delay C3 OFF xxx s Stop delay Compressors 3 0..250 10s
Starts/h X Number of compressor starts per hour 4..100 6
Forced control xxx s Forced control 0..10 5m
Bypass xxx s Bypass 0..60 30s
S Screen 2−5−2 Setpoint toggle (Compressor)
Compr. alt. POS: XXXXX Entry Default
Delay C1 ON xxx s Start delay Compressor 1 0..250 120s
Delay C2 ON xxx s Start delay Compressor 2 0..250 240s
Delay C3 ON xxx s Start delay Compressors 3 0..250 10s
Delay C1 OFF xxx s Stop delay Compressor 1 0..250 75s
Delay C2 OFF xxx s Stop delay Compressor 2 0..250 15s
Delay C3 OFF xxx s Stop delay Compressors 3 0..250 10s
Starts/h X Number of compressor starts per hour 4..100 6
