Menu structure UA 300 D Controller type UR 141
87
E 2007 − ECKELMANN | BERLINER STRASSE 161 | 65205 WIESBADEN | FON +49(0)611 7103-0 | FAX 49(0)611 7103-133 | eckelmann.de
Version 2.03 27. Juni 2008
S Screen 2−3−3 Zone 1A Altern.
FANS 1A POS: XXXXX Entry Default
Fan Delay XX °C Temperature at which fan starts with delay −−, −20..20 −3 °C
Start Delay XX m Cooling start delay 0..60 15m
S Screen 2−3−4 Zone 2A Altern.
FANS 2A POS: XXXXX Entry Default
Fan Delay XX °C Temperature at which fan stops with delay −−, −20..20 2 °C
Overrun Time XX m Fan stop delay 0..60 15m
S Screen 2−4 Alarm
ALARM POS: XXXXX Entry
1 Zone 1 Continue to Screen 2−4−1 1
2 Zone 2 Continue to Screen 2−4−2; shown only when two−zone operation is set
(Screen 6−1)
2
3 Zone 1A Altern. Continue to Screen 2−4−3; shown only when setpoint toggle is enabled
(Screen 3−3)
3
4 Zone 2A Altern. Continue to Screen 2−4−4; shown only when two−zone operation is set
(Screen 6−1) and only when setpoint toggle is enabled (Screen 3−3)
4
S Screen 2−4−1 Zone 1
ALARM 1 POS: XXXXX Entry Default
High Temp Setp XX °C High temperature setpoint at which High Temperature
alarm is generated
−30..30 −12 °C
Low Temp Setp. XX K Low temperature setpoint (difference below temperature
control setpoint) at which Low Temperature alarm is gene-
rated
−−, 0..6 2 K
S Screen 2−4−2 Zone 2
ALARM 2 POS: XXXXX Entry Default
High Temp Setp XX °C High temperature setpoint at which High Temperature
alarm is generated
−30..30 10 °C
Low Temp Setp. XX K Low temperature setpoint (difference below temperature
control setpoint) at which Low Temperature alarm is gene-
rated
−−, 0..6 2 K
S Screen 2−4−3 Zone 1A Altern.
