Version 2.02 15.05.2007 Menu Structure of VS 3000
94
S Masque 3-1-b Transducer /Sensor Matching
TRANSDUCER POS: XXXXX Entrb
Default / Dimension
NT LT Dim.
LP-Transducer → Select signal interface for LP pressure transducer
(4to20mAor0to10V)
→ Screen 3-1-a-a
LP-Min XXX b Pressure at 4 mA or 0 V at LP pressure sensor
output
0..2,0 0,0 0,0 bar
LP-Max XXX b Pressure at 20 mA or 10 V at LP pressure sensor
output
8,0..60,0 10,0 10,0 bar
HP-Transmitter → Select signal interface for HP pressure transducer
(4to20mAor0to10V)
→ Screen 3-1-a-b
HP-Min XXX b Pressure at 4 mA or 0 V at HP pressure sensor
output
0..2,0 1,0 1,0 bar
HP-Max XXX b Pressure at 20 mA or 10 V at HP pressure sensor
output
23,0..150,0 26,0 26,0 bar
S Masque 3-1-b-a LP-T ransducer
TRANSD.LP POS: XXXXX Entry
Default / Dimension
NT LT Dim.
4-20 mA √ 4 to 20 mA at LP pressure sensor output √ √ √ -
0-10 V 0 to 10 V at LP pressure sensor output √ - - -
S Masque 3-1-b-b HP-Transducer
TRANSM.HD POS: XXXXX Entry
Default / Dimension
NT LT Dim.
4-20 mA √ 4 to 20 mA at LP pressure sensor output √ √ √ -
0-10 V 0 to 10 V at LP pressure sensor output √ - - -
S Masque 3-1-c Select Text For Oil/HP Fault
T.Oil/HP-F POS: XXXXX Entry
Default / Dimension
NT LT Dim.
Oil diff. pr. C √ Selected message will be displayed when Oil/HP
F
a
u
l
t
C
o
m
p
r
e
s
s
o
r
x
d
e
t
e
c
t
e
d
t
h
r
o
u
g
h
d
i
g
i
t
a
l
i
n
-
√ √ √ -
HP-Fault Cx
F
a
u
l
t
C
o
m
p
r
e
s
s
o
r
x
d
e
t
e
c
t
e
d
t
h
r
o
u
g
h
d
i
g
i
t
a
l
i
n
-
puts.
√ - - -
Oil/HP-Fault Cx √ - - -
